High-Efficiency LED StripRayMax

- - High efficacy & low power consumption
- - Good bare-board heat dissipation, low light decay
- - Uniform & consistent light color
RayMax range
High efficacy, low power consumption.
RayMax gives high efficacy at low power consumption. Its bare board dissipates heat well for low light decay, and the light colour stays uniform and consistent. 2835 LEDs at 80 to 240 per metre on 24 V, CRI >90, up to 150 lm/W.
- Up to 150 lm/W
- 80 – 240 LEDs/m
- 2200K – 6500K
At a glance
- Voltage
- 24 V
- LED chip
- 2835
- LED density
- 80–240 LEDs/m
- Board width
- 5 · 8 · 10 mm
- Power consumption
- 7.2–22 W/m
- Colour temperature
- 2200–6500K
- CRI
- >90
- Cutting interval
- 33.33–100 mm
- Warranty
- 5 years
Flexible Strips
6 models
RayMaxAP2835-24V-80-8mm
Static white
- Voltage
- 24V
- LEDs/m
- 80
- Power
- 7.2W/m
up to 150 lm/W
View details / Request a quote
RayMaxAP2835-24V-128-8mm
Static white
- Voltage
- 24V
- LEDs/m
- 128
- Power
- 9.6W/m
up to 147 lm/W
View details / Request a quote
RayMaxAP2835-24V-160-5mm
Static white
- Voltage
- 24V
- LEDs/m
- 160
- Power
- 9.6W/m
up to 149 lm/W
View details / Request a quote
RayMaxAP2835-24V-160-8mm
Static white
- Voltage
- 24V
- LEDs/m
- 160
- Power
- 14.4W/m
up to 146 lm/W
View details / Request a quote
RayMaxAP2835-24V-192-10mm
Static white
- Voltage
- 24V
- LEDs/m
- 192
- Power
- 17.5W/m
up to 150 lm/W
View details / Request a quote
RayMaxAP2835-24V-240-10mm
Static white
- Voltage
- 24V
- LEDs/m
- 240
- Power
- 22W/m
up to 141 lm/W
View details / Request a quote
