Vanish
Slim, side-bend, dot-free neon in mini sizes with high brightness.
Vanish is a 24 V DC side-bend flexible neon in three models: VA0410S (4 × 10 mm, 8 W/m), VA0612S (6 × 12 mm, 10 W/m) and VA1225RS (12 × 25 mm, 16 W/m). All three have CRI > 90, a 75 mm bend radius, a 5 m maximum run, IP65 / IP67 ratings and a 3-year warranty.
Series overview
- Models
- VA0410S, VA0612S, VA1225RS
- Sizes
- 4 × 10, 6 × 12, 12 × 25 mm (8, 10, 16 W/m)
- Voltage
- 24 V DC
- Light colours
- Single colour 2200–6500K, tunable white 2700–6500K, RGB on all three; RGBW on VA1225RS
- CRI
- Ra > 90
- IP rating
- IP65 / IP67
- Bend
- Side bend, 75 mm radius
- Warranty
- 3 years
Products
3 of 3 models
VanishVA0410S
4 × 10 mm side-bend neon at 8 W/m, 24 V DC, CRI > 90, in single colour 2200–6500 K, tunable white 2700–6500 K and RGB.
- Size
- 4 × 10 mm
- Power
- 8 W/m
- Voltage
- 24 V DC
View details / Request a quote
VanishVA0612S
6 × 12 mm side-bend neon at 10 W/m, 24 V DC, CRI > 90, in single colour 2200–6500 K, tunable white 2700–6500 K and RGB.
- Size
- 6 × 12 mm
- Power
- 10 W/m
- Voltage
- 24 V DC
View details / Request a quote
VanishVA1225RS
12 × 25 mm round-top side-bend neon at 16 W/m, 24 V DC, CRI > 90, in single colour 2200–6500 K, tunable white 2700–6500 K, RGB and RGBW (3000 K white).
- Size
- 12 × 25 mm
- Power
- 16 W/m
- Voltage
- 24 V DC
View details / Request a quote
Why specify Vanish
Side bend
The neon bends sideways, with a 75 mm bend radius.
Dot-free line
The light shows as a continuous line without visible LED dots.
High brightness
Single-colour output reaches 959 lm/m on the VA1225RS at 5000K.
Mini size, slim and versatile
The smallest model, VA0410S, measures 4 × 10 mm in cross-section, and the VA0612S 6 × 12 mm.
Applications
Need a custom Vanish?
Voltage, CCT, CRI, PCB width, IP construction, reel length and packaging are configured per project. Send us your application and we will recommend a model and prepare samples.
