MechFlex
Modular flexible wall washer in two sizes, rated IP66, with CRI > 90 and a choice of narrow to wide beams.
MechFlex is a flexible wall washer built from linked LED modules, in two models: the 76 mm wide MechFlex404 at 36 W/m and the 26 × 33 mm MechFlex202 at 24 W/m. Both run on 24 V DC in 4000K with CRI > 90, SDCM < 3, IP66 protection and a 3-year warranty.
Series overview
- Models
- MechFlex404, MechFlex202
- Power
- 36 W/m (MechFlex404), 24 W/m (MechFlex202)
- Voltage
- 24 V DC
- Light colours
- 4000K
- CRI
- Ra > 90
- Beam angles
- 15° to 45° plus 15° × 45° (MechFlex404); 20° to 50° plus 20° × 40° and 20° × 60° (MechFlex202)
- IP rating
- IP66
- Warranty
- 3 years
Products
2 of 2 models
MechFlexMechFlex404
76 mm wide modular flexible wall washer at 36 W/m, 24 V DC, CRI > 90, in 4000K, rated IP66.
- Power
- 36 W/m
- Voltage
- 24 V DC
- IP rating
- IP66
View details / Request a quote
MechFlexMechFlex202
26 × 33 mm modular flexible wall washer at 24 W/m, 24 V DC, CRI > 90, in 4000K, rated IP66.
- Power
- 24 W/m
- Voltage
- 24 V DC
- IP rating
- IP66
View details / Request a quote
Why specify MechFlex
Two sizes
The MechFlex404 runs at 36 W/m (1.5 A/m) and the MechFlex202 at 24 W/m (1.0 A/m), both on 24 V DC.
Linked modules
Both models are drawn as rows of LED modules joined end to end: the MechFlex404 in 170, 510 and 1020 mm lengths, the MechFlex202 in 62 mm modules.
Choice of optics
The MechFlex404 offers 15°, 25°, 35° and 45° beams plus 15° × 45°; the MechFlex202 offers 20°, 25°, 35° and 50° beams plus 20° × 40° and 20° × 60°.
IP66 protection
Both models are rated IP66.
Applications
Need a custom MechFlex?
Voltage, CCT, CRI, PCB width, IP construction, reel length and packaging are configured per project. Send us your application and we will recommend a model and prepare samples.
