Lumea
Flexible wall washer with optics integrated into the extrusion for a precise, uniform, dot-free wall wash.
Lumea is a 24 V DC flexible wall washer with optics integrated into its extrusion, made as one model, the 16 × 16 mm Lumea16. It runs at 12 or 16 W/m in 3000K and 4000K (CRI > 90), 15 W/m RGB or 16 W/m RGBW, bends to a 75 mm radius and comes in runs of up to 5 m with a 5-year warranty.
Series overview
- Models
- Lumea16 (16 × 16 mm)
- Power
- 12 or 16 W/m (3000K, 4000K), 15 W/m (RGB), 16 W/m (RGBW) at 24 V DC
- Light colours
- 3000K, 4000K, RGB, RGBW
- CRI
- Ra > 90
- Beam angles
- 22° × 77°, 28° × 82°, 32° × 84°, 40° × 88° (white)
- IP rating
- IP65 / IP67
- Bend
- 75 mm radius (top and side bending); twist up to 540°/m
- Warranty
- 5 years
Products
Why specify Lumea
Integrated extrusion optics
The optics are built into the extrusion to give a precise, uniform wall wash, in four white distributions from 22° × 77° to 40° × 88°.
Compact size, high density
The slim 16 × 16 mm profile delivers up to 1654 lm/m (16 W/m, 4000K).
Soft, dot-free glow
The light appears as a soft, continuous glow without visible LED dots.
Applications
Need a custom Lumea?
Voltage, CCT, CRI, PCB width, IP construction, reel length and packaging are configured per project. Send us your application and we will recommend a model and prepare samples.
