Link
Slim, screwless one-piece aluminium linear wall washers, compact yet powerful.
Link is a range of slim aluminium linear wall washers in five sizes: Link23, Link33, Link36, Link50 and Link60. All have CRI > 90, SDCM < 3, RAL7016 / RAL9005 / RAL9016 finishes and a 3-year warranty; the Link23 runs on 24 V DC, the others on 100–277 V AC or 24 V DC with IP66 protection.
Series overview
- Models
- Link23, Link33, Link36, Link50, Link60
- Power
- 6 W/ft (Link33) to 18 W/ft (Link60); Link23 5.0 or 7.5 W/ft
- Voltage
- 24 V DC (Link23); 100–277 V AC / 24 V DC (Link33–Link60)
- Light colours
- 2700K, 3000K, 4000K, RGB, RGBW (by model)
- CRI
- Ra > 90
- IP rating
- IP20 / IP65 (Link23); IP66 (Link33–Link60)
- Body finish
- RAL7016, RAL9005, RAL9016; custom colours available
- Warranty
- 3 years
Products
5 of 5 models
LinkLink23
16 × 24 mm linear wall washer at 7.5 W/ft (30 W/4 ft) or 5.0 W/ft, 24 V DC, CRI > 90, in 2700K, 3000K, 4000K, RGB and RGBW.
- Power
- 5.0 W/ft or 7.5 W/ft (30 W/4 ft)
- Voltage
- 24 V DC
- IP rating
- IP20 / IP65
View details / Request a quote
LinkLink33
33 × 56.5 mm linear wall washer at 6 W/ft (24 W/4 ft), 100–277 V AC or 24 V DC, CRI > 90, in 3000K and 4000K.
- Power
- 6 W/ft (24 W/4 ft)
- Voltage
- 100–277 V AC / 24 V DC
- IP rating
- IP66
View details / Request a quote
LinkLink36
35.8 × 62.7 mm linear wall washer at 9 W/ft (36 W/4 ft), 100–277 V AC or 24 V DC, CRI > 90, in 3000K and 4000K.
- Power
- 9 W/ft (36 W/4 ft)
- Voltage
- 100–277 V AC / 24 V DC
- IP rating
- IP66
View details / Request a quote
LinkLink50
50 × 69.5 mm linear wall washer at 15 W/ft (60 W/4 ft), 100–277 V AC or 24 V DC, CRI > 90, in 4000K.
- Power
- 15 W/ft (60 W/4 ft)
- Voltage
- 100–277 V AC / 24 V DC
- IP rating
- IP66
View details / Request a quote
LinkLink60
60 × 61.5 mm linear wall washer at 18 W/ft (72 W/4 ft), 100–277 V AC or 24 V DC, CRI > 90, in 4000K.
- Power
- 18 W/ft (72 W/4 ft)
- Voltage
- 100–277 V AC / 24 V DC
- IP rating
- IP66
View details / Request a quote
Why specify Link
Slim, solid aluminium
The body is slim, solid aluminium, from 16 mm wide on the Link23 to 60 mm on the Link60.
Screwless one-piece housing
The housing is a single piece without visible screws, for a clean, minimal look.
Compact yet powerful
Output reaches 5904 lm from a 72 W/4 ft Link60 (30° × 30°, 4000K).
Linear wall wash
Each model washes the wall in a straight line, with optics from 8° × 8° to 60° × 60° and elongated beams such as 25° × 40° and 15° × 60°.
Applications
Need a custom Link?
Voltage, CCT, CRI, PCB width, IP construction, reel length and packaging are configured per project. Send us your application and we will recommend a model and prepare samples.
