ArmorCore
ArmorCore / Static white
SL3030-24V-84-10mm
ArmorCore 3030 White Strip
ArmorCore is designed for LEDs in EMC brackets and PCT packages, and keeps these fragile LEDs reliable on a flexible strip. 3030 LEDs at 84 per metre on 24 V: Nichia LEDs from 1800K to 5000K at CRI >90, or SunLike LEDs at CRI >95.
The printed table gives one product code, SL3030N1890248410S15 (an 1800K code), for all three colour temperatures, so no codes are shown. Confirm the order code with Artcolor.
Full specifications & datasheet
TECHNICAL DATA
- Model No.
- SL3030N-24V-84-10MM
- LED chip
- 3030
- Power consumption
- 14.4 W/m
- Voltage
- 24 V DC
- LED density
- 84 LEDs/m
- Board width
- 10 mm
- CRI
- >95
- Colour consistency
- SDCM <3
- Cutting interval
- 83.33 mm / 3.28 in
- Bend radius
- 60 mm
- Max length
- 5 m / 16.4 ft
- Beam angle
- 117°
- Warranty
- 5 years
Due to manufacturing processes, electronic device characteristics and testing environments, there is a 10% margin of error in testing parameters.
Data under review: The printed table gives one product code, SL3030N1890248410S15 (an 1800K code), for all three colour temperatures, so no codes are shown. Confirm the order code with Artcolor.
IP PROTECTION
- IP20Indoor, bare board
- IP54Nano coating, splash resistant
- IP65Silicone glue, weatherproof
- IP67Silicone tube, temporary immersion
- IP68Solid silicone extrusion, submersible
ELECTRIC PARAMETERS
| Product range | CCT / Channel | CRI | SDCM | Power | Lumen | Efficiency | Efficiency class | Product code |
|---|---|---|---|---|---|---|---|---|
| Armor 3N248410 | 3000K | ≥95 | <3 | 14.4W/m 4.39W/ft | 1263lm/m 384lm/ft | 88lm/w | E | SL3030N1890248410S15 |
| Armor 3N248410 | 4000K | ≥95 | <3 | 14.4W/m 4.39W/ft | 1374lm/m 418lm/ft | 95lm/w | E | SL3030N1890248410S15 |
| Armor 3N248410 | 5000K | ≥95 | <3 | 14.4W/m 4.39W/ft | 1412lm/m 430lm/ft | 98lm/w | D | SL3030N1890248410S15 |
